Handheld Inkjet Printer
EBS260

EBS260


Clear and perfect printing of QR codes, capable of printing 5 lines of information at once, with a maximum printing height of 57mm, equipped with a large touch screen, and integrated printing and editing; Adopting efficient embedded technology Micro Linux computer system, customizable and expandable, making high-level mobile printing possible!

Performance

Detailed

Sample

Download

Nozzle and printing height:

Number of nozzles: 32; Nozzle diameter: 150u (optional 120u、 170u、 200u); The spatial location of machine operation: arbitrary; Height: 8-57mm

Innovative features:

Built in laser locator/ready to locate the printing position; Built in Micro Linux system、 capable of high-level system customization、 and able to connect with various enterprise databases

Power supply:

Power supply: capable of continuous operation for 16 hours at room temperature of 20 degrees Celsius、 with automatic low battery warning function; Charging: Equipped with standard charging (24V/1.25A DC)、 charging time<5 hours

Ink and ink cartridges:

Alcohol based: water-based、 ketone based、 and other colored inks (black and white、 yellow、 blue、 red、 and green); Can be customized according to customer needs; Ink cartridge: easy to remove、 quick to clean and install、 200ml、 capable of printing approximately 300000 7x5 dot matrix characters

Printing speed and control direction:

Speed control: Use wheels to control printing speed or internal pulse control speed; Printing direction: any direction

Number of printing lines:

Up to 5 lines (5X5 dot matrix characters) can be printed at once

Information storage:

Equipped with a 2G memory card; Can store more than 50000 pieces of information; Each message can contain up to 10000 characters

Information editing method:

Edit through PC browser and built-in LCD touch screen

Information content:

Numbers、 letters、 Chinese characters、 QR codes、 images (special graphic symbols for logos)

Spray printing pattern:

Black and white PNG data with a maximum of 32 points

Printing variables:

Configure dedicated registers、 printable variable date and time、 and universal counters

Date format:

editable

Font selection:

Unicode fonts、 True Type vector fonts、 special font area symbols、 image symbols、 etc

Language selection:

English、 Chinese、 German、 Russian、 and other languages can also be easily expanded and added

Standard work pressure:

0.15 bar

Working temperature:

0.5℃℃-40℃

humidity

95% (no condensation)

LCD touch screen:

3.5 "high-definition color touch screen

Weight:

1.58kg (whole machine+ink+battery)

Innovative features:

Built in laser locator、 ready to locate the printing position; Built in Micro Linux system、 capable of high-level system customization、 and able to connect with various enterprise databases

Standard configuration:

Toolbox (for storing and carrying inkjet printers and accessories); Handjet EBS-260 handheld inkjet printer; Ink cartridges、 solvent cartridges; Cleaning pot; Charger and connecting cable; Up and down rollers; Operation Manual

Optional configuration:

Scanning gun、 system application customization、 auxiliary roller bracket
